Complete genome sequence of Actinosynnema mirum type strain (101T)


Actinosynnema mirum Hasegawa et al. 1978 is the type species of the genus, and is of phylogenetic interest because of its central phylogenetic location in the Actinosynnemataceae, a rapidly growing family within the actinobacterial suborder Pseudonocardineae. A. mirum is characterized by its motile spores borne on synnemata and as a producer of nocardicin antibiotics. It is capable of growing aerobically and under a moderate CO2 atmosphere. The strain is a Gram-positive, aerial and substrate mycelium producing bacterium, originally isolated from a grass blade collected from the Raritan River, New Jersey. Here we describe the features of this organism, together with the complete genome sequence and annotation. This is the first complete genome sequence of a member of the family Actinosynnemataceae, and only the second sequence from the actinobacterial suborder Pseudonocardineae. The 8,248,144 bp long single replicon genome with its 7100 protein-coding and 77 RNA genes is part of the Genomic Encyclopedia of Bacteria and Archaea project.


Strain 101T (DSM 43827 = ATCC 29888 = NBRC 14064, and other culture collections) is the type strain of Actinosynnema mirum, which is the type species of the genus Actinosynnema [1] (Figure 1). A. mirum was described by Hasegawa et al. in 1978 [1] as an aerobic actinobacterium which forms synnemata (compacted groups of erect hyphae which bear conidia) with zoospores [1]. The organism is of interest due to its position in the tree of life where the small genus Actino-synnema, currently comprising only two species, is located on a rather long branch within the rapidly growing actinobacterial suborder Pseudo-nocardineae [2]. We here present a summary classification and a set of features for A. mirum strain 101T (Table 1), together with the description of the complete genomic sequencing and annotation.

Figure 1.

Phylogenetic tree highlighting the position of A. mirum 101T relative to all type strains of the genus and to the type strains of the type species of all other genera within the family. The tree was inferred from 1,491 aligned characters [5,6] of the 16S rRNA gene sequence under the maximum likelihood criterion [7] and rooted in accordance with current actinobacterial taxonomy. The branches are scaled in terms of the expected number of substitutions per site. Numbers above branches are support values from 1,000 bootstrap replicates if larger than 60%. Lineages with a type strain genome-sequencing project registered in GOLD [8] are printed in blue; published genomes in bold.

Table 1. Classification and general features of A. mirum 101T in accordance with the MIGS recommendations [13]

Classification and features

No closely related cultivated strains are known from the literature that can be linked to the species A. mirum. Curiously, the 16S rRNA gene sequences of the type strains from the two subspecies within the second species of the genus Actinosynnema, A. pretiosum subsp. auranticum (AB303364) and A. pretiosum subsp. pretiosum (AB303365) [3], seem to have an equally or even higher degree of similarity to the 16S rRNA gene sequence derived from the genome sequence reported here than the previously reported gene sequences of strain 101T (see Figure 1). None of the phylotypes reported from environmental screenings or genomic surveys could be linked to A. mirum with a convincing degree of sequence similarity (maximal observed degree of similarity 92%; status June 2009).

A. mirum strain 101T cells are non-motile with fine hyphae which form aerial and substrate mycelia. Both the aerial and substrate mycelia are about 0.5 to 1.0 µm in diameter. Aerial mycelia are long branching hyphae, white to pale yellow in color (Figure 2). The substrate mycelia are also long, branching hyphae, white to yellowish orange, and penetrate into the agar medium and form synnemata [1]. Cells stain Gram-positive and are non-acid fast [1].

Figure 2.

Scanning electron micrograph (SEM) of A. mirum 101T. More SEMs of A. mirum can be found in the Compendium of the Actinobacteria, by Joachim M. Wink, University of Braunschweig.

A. mirum is capable of producing a yellowish-brown soluble pigment on tyrosine agar and a pale greenish pigment on oatmeal agar [1]. Capable of hydrolyzing starch, casein, tyrosine and gelatin, but not xanthine, hypoxanthine, adenine and urea [1]; produces nitrate reductase and phosphatase. Positive for utilization of tartrate, pyruvate, lactate and malate, but negative for benzoate, acetate, citrate and succinate [1]. Acid is produced aerobically from fructose, lactose, maltose, D-mannitol, L-arabinose, D-melibiose, D-mannose, L-rhamnose, xylose, dextrin, galactose, glucose, trehalose, raffinose, starch, sucrose, cellobiose, glycogen and adonitol, but not from inositol, sorbitol, D-ribose, salicin, inulin, glycerol, dulcitol, erythritol, α-methyl-D-glucoside and α-methyl-D-mannoside. A. mirum is a producer of nocardicin antibiotics [4] and inhibits the growth of several Gram-positive bacteria including: Bacillus megaterium, Sarcina lutea, Mycobacterium smegmatis; as well as the filamentous fungi, Aspergillus niger, Penicillium notatum and the yeasts, Saccharomyces cerevisiae and Candida tropicalis.

Figure 1 shows the phylogenetic neighborhood of A. mirum strain 101T in a 16S rRNA based tree. The sequences of the five 16S rRNA genes in the A. mirum genome differ by no more than one nucleotide (nt) from each other, and by up to six nts from the previously reported reference sequences derived from NBRC 14064 (AF328679) and from DSM 43827 (X84447). The differences between the genome data and the previously reported 16S rRNA gene sequence are probably due to sequencing errors in the previously reported sequence data.


The peptidoglycan of A. mirum contains meso-diaminopimelic acid in addition to alanine, glutamic acid and glucosamine. Galactose and mannose are present in the cell wall sugars, whereas madurose is absent. Cell wall type III has been detected, as well as whole-cell sugar pattern of type C [1]. The fatty acid pattern of strain 101T is dominated by saturated straight chain acids, C17:0 (15.2%), C16:0 (4.8%), C15:0 (2.6%), and branched chain acids, anteiso-(ai-)C13:0 (11.6%), ai-C15:0 (5.9%), ai-C17:0 (4.5%), ai-C11:0 (2.3%), and iso-(i-)C12:0 (11.3%), i-C16:0 (7.5%), i-C14:0 (3.5%), i-C15:0 (2.1%), i-C11:0 (1.5%). Unsaturated straight chain acids play only a limited role: C17:1 cis9 (11.3%), and C16:1 cis9 (3.4%) are present, whereas unsaturated branched chain fatty acids are absent. Minor amounts of hydroxylated fatty acids were detected: C16:1 2OH (1.0%), ai-C15:0 2OH (0.9%), and C15:0 3OH (0.5%) [Cellular fatty acids data from RM Kroppenstedt, DSMZ, unpublished]. The published literature on the fatty acid patterns is, however, contradictory, with Hasegawa et al. [3], and Yassin et al [9]. emphasizing the presence of branched chain fatty acids (including a 10-methyl C18:0), but neither unsaturated nor hydroxylated fatty acids are reported. The major polar lipids present are: diphosphatidylglycerol (DPG), phosphatidylethanolamine (PE), phosphatidyl inositol mannosides (PIM) and phosphatidylinositol (PI) [9]. Hydroxy-phosphatidylethanolamine (OH-PE) has been reported by some authors [10,12], but not by others [9,10]. MK-9(H4) and MK-9(H6) are the predominant menaquinones [9].

Genome sequencing and annotation

Genome project history

This organism was selected for sequencing on the basis of its phylogenetic position, and is part of the Genomic Encyclopedia of Bacteria and Archaea project. The genome project is deposited in the Genomes OnLine Database [8] and the complete genome sequence in GenBank (CP001630). Sequencing, finishing and annotation were performed by the DOE Joint Genome Institute (JGI). A summary of the project information is shown in Table 2.

Table 2. Genome sequencing project information

Growth conditions and DNA isolation

A. mirum strain 101T, DSM 44827, was grown in DSMZmedium535 (GYM Streptomyces Medium at 28°C. DNA was isolated from 1–1.5 g of cell paste using Qiagen Genomic 500 DNA Kit (Qiagen, Hilden, Germany) with a modified lysis buffer (1 ml achromopeptidase and 0.5 ml lysostaphin added) and one hour incubation at 37°C.

Genome sequencing and assembly

The genome was sequenced using a combination of Sanger and 454 sequencing platforms. All general aspects of library construction and sequencing performed at the JGI can be found on the JGIwebsite. 454 Pyrosequencing reads were assembled using the Newbler assembler version (Roche). Large Newbler contigs were broken into 10,493 overlapping fragments of 1,000 bp and entered into assembly as pseudo-reads. The sequences were assigned quality scores based on Newbler consensus q-scores with modifications to account for overlap redundancy and to adjust inflated q-scores. A hybrid 454/Sanger assembly was made using the phrap assembler (High Performance Software, LLC). Possible mis-assemblies were corrected with Dupfinisher or transposon bombing of bridging clones [16]. Gaps between contigs were closed by editing in Consed, custom primer walk or PCR amplification. 1,564 Sanger finishing reads were produced to close gaps and to raise the quality of the finished sequence. The error rate of the completed genome sequence is less than 1 in 100,000. Together all sequence types provided 28.9x coverage of the genome. The final assembly contains 105,508 Sanger reads in addition to the 454 based pseudo reads.

Genome annotation

Genes were identified using Prodigal [17] as part of the Oak Ridge National Laboratory genome annotation pipeline, followed by a round of manual curation using the JGI GenePRIMP pipeline [18]. The predicted CDSs were translated and used to search the National Center for Biotechnology Information (NCBI) nonredundant database, UniProt, TIGRFam, Pfam, PRIAM, KEGG, COG, and InterPro databases. Additional gene prediction analysis and functional annotation was performed within the IntegratedMicrobialGenomes (IMG-ER) platform [19].

Genome properties

The genome is 8,248,144 bp long and comprises one circular chromosome with a 73.7% GC content (Table 3 and Figure 3). Of the 7,174 genes predicted, 7100 were protein coding genes, and 74 RNAs., One hundred and eight four pseudogenes were also identified. The majority of genes (67.3%) of the genes were assigned a putative function while the remaining ones were annotated as hypothetical proteins. The prop-erties and the statistics of the genome are summarized in Table 3. The distribution of genes into COGs functional categories is presented in Table 4.

Figure 3.

Graphical circular map of the genome. From outside to the center: Genes on forward strand (color by COG categories), Genes on reverse strand (color by COG categories), RNA genes (tRNAs green, rRNAs red, other RNAs black), GC content, GC skew.

Table 3. Genome Statistics
Table 4. Number of genes associated with the 21 general COG functional categories


  1. 1.

    Hasegawa T, Lechevalier MP, Lechevalier HA. A new genus of Actinomycetales: Actinosynnema gen. nov. Int J Syst Bacteriol 1978; 28:304–310 doi:10.1099/00207713-28-2-304

    Article  Google Scholar

  2. 2.

    Stackebrandt E, Rainey F, Ward-Rainey N. Proposal for a new hierarchic classification system, Actinobacteria classis nov. Int J Syst Bacteriol 1997; 47:479–491 doi:10.1099/00207713-47-2-479

    Article  Google Scholar

  3. 3.

    Hasegawa T, Tanida S, Hatano K, Higashide E, Yoneda M. Motile actinomycetes: Actinosynnema pretiosum subsp. pretiosum sp. nov., subsp. nov., and Actinosynnema pretiosum subsp. auranticum subsp. nov. Int J Syst Bacteriol 1983; 33:314–320 doi:10.1099/00207713-33-2-314

    Article  Google Scholar

  4. 4.

    Watanabe K, Okuda T, Yokose K, Furumai T, Maruyama HB. Actinosynnema mirum, a new producer of nocardicin antibiotics. J Antibiot (Tokyo) 1983; 36:321–324 PMID:6833153

    Article  CAS  Google Scholar

  5. 5.

    Lee C, Grasso C, Sharlow MF. Multiple sequence alignment using partial order graphs. Bioinformatics 2002; 18:452–464 PMID:11934745 doi:10.1093/bioinformatics/18.3.452

    Article  CAS  PubMed  Google Scholar

  6. 6.

    Castresana J. Selection of conserved blocks from multiple alignments for their use in phylogenetic analysis. Mol Biol Evol 2000; 17:540–552 PMID:10742046

    Article  CAS  PubMed  Google Scholar

  7. 7.

    Stamatakis A, Hoover P, Rougemont J. A rapid bootstrap algorithm for the RAxML Web servers. Syst Biol 2008; 57:758–771 PMID:18853362 doi:10.1080/10635150802429642

    Article  PubMed  Google Scholar

  8. 8.

    Liolios K, Mavromatis K, Tavernarakis N, Kyrpides NC. The Genomes On Line Database (GOLD) in 2007: status of genomic and metagenomic projects and their associated metadata. Nucleic Acids Res 2008; 36:D475–479 PMID:17981842 doi:10.1093/nar/gkm884

    PubMed Central  Article  CAS  PubMed  Google Scholar

  9. 9.

    Yassin AF, Rainey FA, Brzezinka H, Jahnke KD, Weissbrodt H, Budzikiewicz H, Stackebrandt E, Schaal KP. Lentzea gen. nov., a new genus of the order Actinomycetales. Int J Syst Bacteriol 1995; 45:357–363 PMID:7537071

    Article  CAS  PubMed  Google Scholar

  10. 10.

    Labeda DP, Hatano K, Kroppenstedt RM, Tamura T. Revival of the genus Lentzea and proposal for Lechevalieria gen. nov. Int J Syst Evol Microbiol 2001; 51:1045–1050 PMID:11411672

    Article  CAS  PubMed  Google Scholar

  11. 11.

    Labeda DP, Kroppenstedt RM. Phylogenetic analysis of Saccharothrix and related taxa: proposal for Actinosynnemataceae fam. nov. Int J Syst Evol Microbiol 2000; 50:331–336 PMID:10826820

    Article  CAS  PubMed  Google Scholar

  12. 12.

    Labeda DP, Kroppenstedt RM. Proposal of Umezawaea gen. nov., a new genus of the Actinosynnemataceae related to Saccharothrix, and transfer of Saccharothrix tangerinus Kinoshita et al. 2000 as Umezawaea tangerina gen. nov., comb. nov. Int J Syst Evol Microbiol 2007; 57:2758–2761 PMID:18048721 doi:10.1099/ijs.0.64985-0

    Article  CAS  PubMed  Google Scholar

  13. 13.

    Field D, Garrity G, Gray T, Morrison N, Selengut J, Sterk P, Tatusova T, Thomson N, Allen MJ, Angiuoli SV, et al. The minimum information about a genome sequence (MIGS) specification. Nat Biotechnol 2008; 26:541–547 PMID:18464787 doi:10.1038/nbt1360

    PubMed Central  Article  CAS  PubMed  Google Scholar

  14. 14.

    Anonymous. Biological Agents: Technical rules for biological agents. <>.

  15. 15.

    Ashburner M, Ball CA, Blake JA, Botstein D, Butler H, Cherry JM, Davis AP, Dolinski K, Dwight SS, Eppig JT, et al. Gene ontology: tool for the unification of biology. The Gene Ontology Consortium. Nat Genet 2000; 25:25–29 MID:10802651 doi:10.1038/75556

    PubMed Central  Article  CAS  PubMed  Google Scholar

  16. 16.

    Sims D, Brettin T, Detter JC, Han C, Lapidus A, Copeland A, Del Rio TG, Nolan M, Chen F, Lucas S, et al. Complete genome of Kytococcus sedentarius type strain (541T). SIGS 2009; 1:12–20 doi:10.4056/sigs.761

    PubMed Central  PubMed  Google Scholar

  17. 17.

    Anonymous. Prodigal Prokaryotic Dynamic Programming Genefinding Algorithm. Oak Ridge National Laboratory and University of Tennessee 2009 <>

  18. 18.

    Pati. GenePRIMP: A Gene Prediction Improvement Pipeline for microbial genomes. (Submitted)

  19. 19.

    Markowitz V, Mavromatis K, Ivanova N, Chen IM, Chu K, Kyrpides N. Expert Review of Functional Annotations for Microbial Genomes. Bioinformatics 2009 (In press)

Download references


We gratefully acknowledge the help of Marlen Jando for growing A. mirum cultures and Susanne Schneider for DNA extraction and quality analysis (both at DSMZ). This work was performed under the auspices of the US Department of Energy’s Office of Science, Biological and Environmental Research Program, and by the University of California, Lawrence Berkeley National Laboratory under contract No. DE-AC02-05CH11231, Lawrence Livermore National Laboratory under Contract No. DE-AC52-07NA27344, and Los Alamos National Laboratory under contract No. DE-AC02-06NA25396, as well as German Research Foundation (DFG) INST 599/1-1.

Author information



Corresponding author

Correspondence to Hans-Peter Klenk.

Rights and permissions

This article is published under license to BioMed Central Ltd. This is an Open Access article distributed under the terms of the Creative Commons Attribution License (, which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly credited. The Creative Commons Public Domain Dedication waiver ( applies to the data made available in this article, unless otherwise stated.

Reprints and Permissions

About this article

Cite this article

Land, M., Lapidus, A., Mayilraj, S. et al. Complete genome sequence of Actinosynnema mirum type strain (101T). Stand in Genomic Sci 1, 46–53 (2009).

Download citation


  • Synnemata
  • motile spores
  • soluble pigments
  • mesophile
  • aerobic
  • aerial and substrate mycelium
  • nocardicin A producer
  • Actinosynnemataceae
